SMD QUARTZ 5,0 x 3,2 mm 8,0 - 133,0 MHz
- SMD oscilační křemen 5,0 x 3,2 mm
- Vysoká spolehlivost za příznivou cenu
- K dispozici je rozšířený teplotní rozsah až do -40/+125 °C
- K dispozici je tolerance frekvence ±10ppm@+25°C, úzká teplotní stabilita a minimální hodnoty stárnutí
- Kvalifikace pro použití v automobilovém průmyslu
- Konstrukce krystalu se sníženým odporem (technologie LRT ) pro rychlou a bezpečnou přechodovou odezvu
Název produktu
SMD Quartz Crystal
Pouzdro
SMD Ceramic/4pad
Rozměry v mm
5.0 x 3.2 x 0.8 mm
Rozsah frekvence
8.00 - 133.00 MHz
DELIVERY FORM
Tape and Reel (1.000 pcs per reel)
STORAGE TEMPERATURE
-55°+125°C
INSULATION RESISTANCE
>500 MΩ DC/100V ±10%
AGING
±2 ppm per year standard (±1 ppm available as option)
DRIVE LEVEL 3rd Overtone
100 μW typ. / 200 μW max. (300 μW available on request)
DRIVE LEVEL Fundamental
100 μW typ. / 200 μW max. (300 μW available on request)
SHUNT CAPACITANCE C0
3 pF max.
WORKING TEMPERATURE RANGES
0/+50°C ~ -40/+125°C
LOAD CAPACITANCE (CL)
6 pF ~ 50 pF or Series
FREQUENCY TOLERANCES AT 25°C
±8 ppm ~ ±50 ppm
STANDARD FREQUENCIES
8.0000 MHz / 8.1920 MHz / 8.7040 MHz / 9.2160 MHz / 9.7500 MHz / 9.8136 MHz / 9.81713 MHz / 9.8304 MHz / 9.84375 MHz / 9.9000 MHz / 9.984625 MHz / 10.0000 MHz / 10.3680 MHz / 10.7750 MHz / 10.78125 MHz / 11.0592 MHz / 11.2896 MHz / 12.0000 MHz / 12.2880 MHz / 12.5000 MHz / 12.8000 MHz / 13.0000 MHz / 13.225625 MHz / 13.4000 MHz / 13.40568 MHz / 13.5000 MHz / 13.5010 MHz / 13.5020 MHz / 13.5030 MHz / 13.5040 MHz / 13.5050 MHz / 13.5060 MHz / 13.5200 MHz / 13.52172 MHz / 13.5240 MHz / 13.5260 MHz / 13.5280 MHz / 13.5296 MHz / 13.5300 MHz / 13.542969 MHz / 13.5440 MHz / 13.5596 MHz / 13.5600 MHz / 13.5672 MHz / 13.568125 MHz / 13.57187 MHz / 13.5750 MHz / 13.8240 MHz / 14.0000 MHz / 14.31818 MHz / 14.4000 MHz / 14.7456 MHz / 15.0000 MHz / 15.3600 MHz / 16.0000 MHz / 16.3680 MHz / 16.3840 MHz / 16.9344 MHz / 17.6133 MHz / 17.734475 MHz / 18.4320 MHz / 18.9375 MHz / 19.0000 MHz / 19.069928 MHz / 19.2000 MHz / 19.4400 MHz / 19.6608 MHz / 19.941944 MHz / 20.000 MHz / 20.0800 MHz / 20.1646 MHz / 20.4800 MHz / 21.1450 MHz / 21.948717 MHz / 22.1184 MHz / 22.5790 MHz / 22.5792 MHz / 24.0000 MHz / 24.5760 MHz / 24.8832 MHz / 25.0000 MHz / 25.78125 MHz / 26.0000 MHz / 26.7400 MHz / 26.7600 MHz / 27.0000 MHz / 27.1200 MHz / 28.0000 MHz / 28.2240 MHz / 28.3220 MHz / 28.3750 MHz / 28.63636 MHz / 29.4912 MHz / 30.0000 MHz / 30.7200 MHz / 32.0000 MHz / 32.7680 MHz / 33.0000 MHz / 33.3000 MHz / 33.3330 MHz / 35.3280 MHz / 36.0000 MHz / 37.0500 MHz / 37.4000 MHz / 37.5000 MHz / 38.3830 MHz / 38.8800 MHz / 39.0620 MHz / 39.0640 MHz / 40.0000 MHz / 40.9600 MHz / 41.0000 MHz / 44.0000 MHz / 48.0000 MHz / 49.1520 MHz / 50.0000 MHz / 64.0000 MHz / 99.9947 MHz
FREQUENCY RANGES (SEPARATED)
8.0 ~ 54.0 MHz Fundamental
54.0 ~ 133.0 MHz 3rd Overtone
| ±5 ppm | ±10 ppm | ±15 ppm | ±20 ppm | ±30 ppm | ±50 ppm | |
|---|---|---|---|---|---|---|
| 0/50 °C | • | • | • | • | • | • |
| -10/60 °C | • | • | • | • | • | • |
| 0/70 °C | • | • | • | • | • | • |
| -20/70 °C | • | • | • | • | • | |
| -40/85 °C | • | • | • | • | ||
| -40/105 °C | • | • | ||||
| -40/125 °C | • |
DATASHEET: SMD QUARTZ CRYSTAL SMD0503-4
